Shantui Parts SD22 Bolt and Nut M22 155-27-12181 01803-02228
Part Name:Bolt and Nut
Part Number: 155-27-12181 01803-02228
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY | |
| SD22,SD22E, | SD22R, | |||
| SD22D | SD22S | |||
| 1 | 154-27-12313 | Half shaft | 2 | |
| 1 | 158-18-00001 | Half shaft | 2 | |
| 2 | 170-27-12472 | Nut | 2 | 2 |
| 3 | 09243-01230 | Pin | 2 | 2 |
| 4 | 170-27-12480 | Ring | 2 | 2 |
| 5 | 154-27-12131 | Sprocket hub | 2 | 2 |
| 6 | 154-27-12273 | Sprocket | 14 | 14 |
| 7 | 154-27-12283 | Sprocket | 4 | 4 |
| 8 | 155-27-12181 | Bolt | 50 | 50 |
| 9 | 01803-02228 | Nut | 50 | 50 |
| 10 | 170-27-12232 | Sprocket hub nut | 2 | 2 |
| 11 | 07000-15315 | O-ring | 2 | 2 |
| 12 | 175-27-31480 | Plate | 2 | 2 |
| 13 | 170-27-12250 | Positioning pin | 4 | 4 |
| 14 | 01252-71635 | Screw | 2 | 2 |
| 16 | 04000-01280 | Flat key | 2 | 2 |
| 17 | 154-27-12352 | Bush | 2 | 2 |
| 18 | 198-30-16612 | Oil seal,Float | 4 | 4 |
| 19 | 170-27-12340 | O-ring | 4 | 4 |
| 20 | 154-27-12334 | Support | 2 | 2 |
| 21 | 154-27-12341 | Bushing | 2 | 2 |
| 22 | 04020-01638 | Cylindrical pin | 2 | 2 |
| 23 | 175-27-32510 | Positioning pin | 2 | 2 |
| 24 | 154-27-12424 | Gasket | 2 | 2 |
| 25 | 154-27-12412 | Nut | 2 | 2 |
| 26 | 154-27-15240 | Bolster | 2 | 2 |
| 27 | 154-27-15250 | Plate | 2 | 2 |
| 28 | 01010-51020 | Bolt | 4 | 4 |
| 29 | 02892-03148 | O-ring | 2 | 2 |
| 30 | 154-27-12362 | Cover | 2 | 2 |
| 31 | 01010-51640 | Bolt | 12 | 12 |
| 32 | 01643-31645 | Washer | 14 | 14 |
